| Device Type |
Multifunction Printer |
| Product Category |
Office |
| Colour or Mono |
Mono |
| Print Speed |
21-30 PPM |
| Mono Output Speed (A4 pages per min) |
30 |
| Print Resolution(dpi) |
1200 x 1200 |
| Copy Resolution (dpi) |
600 x 600 |
| First Time To Print Mono (secs) |
5.4 |
| First Time To Print Colour (secs) |
4GB |
| Warm Up Time (secs) |
20 |
| Output Size Max |
SRA3 |
| Average Monthly Volume (A4 pages per mth) |
10,000 |
| Standard Paper Input Tray 1 (Sheets) |
500 |
| Standard Paper Input Tray 2 (Sheets) |
500 |
| Standard Paper Input Tray 3 (Sheets) |
1500 |
| Standard Paper Input Tray 4 (Sheets) |
1000 |
| Standard Paper Input Multiple Bypass (sheets) |
150 |
| Standard Paper Input High Capacity Feeder |
300 |
| Maximum Paper Input (sheets) |
6650 |
| Paper Weight Trays (gsm) |
52-256 |
| Paper Weight Multiple Bypass (gsm) |
52-300 |
| Standard Memory (GB) |
4GB |
| Hard Drive Standard |
250GB |
| Document Feeder (sheets) |
Std RADF |
| Weight (kg) |
76.5kg |
| Dimension W x D x H (mm) |
615 x 725 x 779 |
| Dimension Inclusions |
Main unit, ADF, 2 Trays |
| Power Requirements (V / Amp / Hz) |
220-240V |
| Max Power Consumption (kW) |
1580 |
| Energy Star Typical Energy Consumption (kWh/week) |
1.5kWh |
| Scan Type |
Full Colour Scanner |
| Scanning Speed Simplex Max (ipm) |
80 |
| Scanning Speed Duplex Max (ipm) |
160 |
| Interface |
Ethernet 10BASE-T/100BASE-TX/1000BASE-T |
| Protocol |
TCP/IP (FTP, SMB, SMTP) |
| Dual Scan |
Yes |
| Scanning Size Max |
A3 |
| Scan Resolution |
Push: 200x200 / 300x300 / 400x400 / 600x600 dpiPull: 100x100 / 200x200 / 300x300 / 400x400 / 600x600 dpi |
| Output Format |
JPEG/TIFF/PDF/PDF/A 1a/1b (opt); Compact PDF; encrypted PDF; searchable PDF (opt); XPS; compact XPS; PPTX; searchable DOCX/XLSX (opt), searchable PPTX |
| Main Functions |
Scan to E-mail, Scan to FTP, Scan to Box (HDD), Scan to PC (SMB), Network TWAIN, Scan to WebDAV, Scan to Me, Scan to Home, Scan to USB, Scan to Scan Server, Scan to Web Service (WSD-Scan), Device Profile for Web Services (DPWS) |
| Modem Type |
Super G3 |
| Modem Speed |
2.4 – 33.6 Kbps |
| Transmission Speed |
2 |
| Scanning Speed |
240 |
| Number of Stored Destinations |
2000 |
| Number of One Touch Destinations |
400 |
| Number of Group Destinations |
100 |
| Internet Fax Protocol |
SMTP, POP3, TCP/IP |
| Internet Fax Resolution |
200x100 / 200x200 / 400x400 / 600x600 dpi |
| Internet Fax Interface |
Ethernet 10Base-T/100Base-T/1000Base-T |
| Internet Fax Colour |
Yes |
| Send and Receive File Format |
Send: TIFF-F, Receive: TIFF-F, Colour/ Grey Scale: TIFF (RFC3949 Profile-C) |
| Operating System Support |
Windows Vista (32/64), Windows 7 (32/64), Windows 8/8.1 (32/64), Windows 10 (32/64), Windows Server 2008 (32/64), Windows Server 2008 R2 (64), Windows Server 2012/R2 (64), Macintosh OS X 10.6, Unix, Linux, Citrix, SAP. AS/400 |
| Processor |
1.2GHz |
| Supported Protocols |
TCP/IP (IPv4, IPv6), IPX/SPX (ND support), SMB (netBEUI), LPD, IPP 1.1, SNMP, HTTP |
| Memory |
4GB (shared among all MFP functions) |
| Printer Language |
PCL6 (Ver. 3.0) Emulation, PCL5e Emulation,PostScript 3 Emulation (3016), XPS Ver. 1.0 |
| Printer Interface |
10BaseT/100BaseT/1000 BaseT, USB 2.0, USB Host, Wi-Fi 802.11b/g/n (optional) |
